60mm Gear Box for Size 57BYGH Hybrid Motor

Item

Specifications

Step Angle Accuracy

± 5% (full step, no load)

Resistance Accuracy

± 10%

Inductance Accuracy

± 20%

Temperature Rise

80°C Max. (rated current, 2 phase on)

Ambient Temperature

- 10°C ~ +50°C

Insulation Class

B

Dielectric Strength

500 VAC for one minute

Shaft Radial Play

0.06 Max. (450 g-load)

Shaft Axial Play

0.08 Max. (450 g-load)

Model No.

Voltage

Current

Resistance

Inductance

Output Torque

Holding Torque

#  of Leads

Step Angle

Gear
 ratio

L

V

A

W

mH

Oz-in

Kg-cm

Oz-in

Kg-cm

Full step

mm

57BYGH422-G36

5.7

1

5.7

5.4

1423

102.5

54

3.9

6

0.050°

36

42

57BYGH516-G30

2.2

3

0.74

1.1

2190

157.5

100

7.2

6

0.060°

30

52

57BYGH603-G20

3.6

2

1.8

3.7

1825

131.4

125

9

6

0.090°

20

56

57BYGH701-G18

3.2

2.8

1.13

5.4

3827

275.6

262

18.9

4

0.100°

18

76

57BYGH9503-G10

2.32

2.8

0.83

3.5

810

58.3

100

7.2

4

0.090°

10

52

57BYGH9605-G5

2.24

2.8

0.8

4.5

450

32.4

111

8.0

4

0.180°

5

56

57BYGH9704-G3.6

8.6

1.0

8.6

23

526

38

180

13

6

0.250°

3.6

76
