1.8 Size 57BYG Hybrid Stepping Motor

Item

Specifications

Step Angle Accuracy

± 5% (full step, no load)

Resistance Accuracy

± 10%

Inductance Accuracy

± 20%

Temperature Rise

80°C Max. (rated current, 2 phase on)

Ambient Temperature

- 10°C ~ +50°C

Insulation Class

B

Dielectric Strength

500 VAC for one minute

Shaft Radial Play

0.06 Max. (450 g-load)

Shaft Axial Play

0.08 Max. (450 g-load)

Model No.

Rated Voltage

Current

Resistance

Inductance

Holding Torque

# of Leads

Rotor Inertia

Weight

Length

Single Shaft

Double Shaft

V

A

W

mH

Oz-in

Kg-cm

g-cm2

Kg

mm

57BYG402

57BYG402B

1.8

2.4

0.75

1.3

56

4

4

60

0.45

42

57BYG415

57BYG415B

10.8

0.45

24

25

40

2.88

6

57BYG417

57BYG417B

2.3

1.5

1.5

1.6

40

2.88

6

57BYG503

57BYG503B

5.1

1.0

5.1

7

69

4.97

6

118

0.6

52

57BYG508

57BYG508B

2.8

2.0

1.4

1.8

69

4.97

6

57BYG513

57BYG513B

2.1

2.5

0.85

2.5

96

6.9

4

57BYG608

57BYG608B

3.4

2.1

1.6

2.6

84

6.05

6

135

0.65

57

57BYG610

57BYG610B

3

2.5

1.2

4

117

8.4

4

57BYG619

57BYG619B

2.5

3.5

0.7

1.7

117

8.4

4

57BYG702

57BYG702B

3

3.0

1

4.6

167

12

4

230

1.0

77

57BYG706

57BYG706B

5.4

1.5

3.6

7.8

125

9

6
